Anderson PowerMod® Connector Series














POWERMOD® CONNECTOR SERIES
(UP TO 30 AMPS)

The Anderson Power Product's PowerMod® connector family was developed to provide a high density power connector system with maximum design flexibility.

The product family is available in 13 sizes:
  • Single row 3, 4, 6 and 8 circuit connector

  • Two row 6, 8, 12 and 16 circuit connectors

  • Three row 9, 12, 18, 24 and 30 circuit connectors

The PowerMod® connector family can be configured for almost any application:
  • Male PCB solder mount straight and right angle

  • Female PCB solder mount straight and right angle

  • Male cable to cable straight

  • Female cable to cable straight
The product family also offers optional positive latches, back shells and panel mounting clips.

The PowerMod® connector family offers even more application flexibility with up to four sequential pin mating options for Make First / Break Last and Make Last / Break First circuits.

Anderson Power Products

FEATURES

POWERMOD® CONNECTOR SERIES (UP TO 30 AMPS) FEATURES

  • High performance #16 contact

  • Mechanical polarized housings

  • PCB, panel or cable mounting

  • Optional positive latches and back shells

  • Optional sequential contact mating


BENEFITS

POWERMOD® CONNECTOR SERIES (UP TO 30 AMPS) BENEFITS

  • Rated to 30 amps per IEC512-3 test 5a

  • Housings only mate one-way, ensuring proper circuit mating

  • Product flexibility for a wide variety of system packaging

  • Provides additional safety and security

  • Up to 4 pin contact lengths can be specified to create

  • Make First / Break Last and Make Last / Break First circuits
