PP 180 Powerpole® Connector (Up To 350 Amps)

Anderson PP 180 Powerpole® Connector

PP 180 POWERPOLE® CONNECTOR (UP TO 350 AMPS)

Powerpole® connectors provide cost effective reliability, design flexibility and safety for your products' manufacture, installation and maintenance. Powerpoles are stackable and color-coded.

The housings are modular and genderless. Powerpole® connectors provide 600 Volts continuous, AC or DC operation. With the addition of the extended range contacts, the PP Plus Connector now accepts a 3/0 wire size, increasing the amperage using the same robust housing. Wire sizes range from 3/0 to #10 AWG (85.0 to 5.3 mm²).

Anderson Power Products

FEATURES

PP 180 POWERPOLE® CONNECTOR (UP TO 350 AMPS) FEATURES

  • Flat wiping contact system

  • Colored modular housings

  • Molded-In dovetails


BENEFITS

PP 180 POWERPOLE® CONNECTOR (UP TO 350 AMPS) BENEFITS

  • Minimal contact resistance at high current, wiping action cleans contact surface during connection/disconnection

  • Provides visual identification of proper mating connector

  • Secures individual connectors into "keyed" assemblies which prevents misconnection with similar configurations
