4 Position SPEC Pak® (15 To 40 Amps)

Anderson 4 Position SPEC Pak®




4 POSITION SPEC PAK®
(15 TO 40 AMPS)

APP®’s SPEC Pak® Connector Series uses rugged and environmentally sealed (IP68) shells to protect existing APP® Powerpole® contacts and housings. Customer configured SPEC Pak® Connectors may be used anywhere a rugged and waterproof high-power interconnect with signal and ground capabilities is required such as in; mass transportation, off-road vehicles, factory automation, oil and petrochemical exploration, agricultural equipment, and many more.

The core APP® Powerpole® technology within the SPEC Pak® is proven reliable and cost effective. The broad selection of touch safe, color-coded Powerpole® housings with power, signal and ground contacts accept a broad range of wire gauges, #24 to #10 AWG (0.25 to 4.0 mm2), giving users thousands of flexible design solutions in a single interconnect.

Anderson Power Products

4 POSITION SPEC PAK® (15 TO 40 AMPS) FEATURES

  • Environmentally sealed (IP68) shells

  • Rugged, safe & versatile shells

  • 40A per contact at 600 volts

  • Power, signal & ground contacts available

  • Up to 4 power or 16 signal circuits

  • Touch safe connections on both side

  • Color-coding capabilities for ease of assembly

  • Other configurations available
