Home Anderson Power Products SPEC Pak® Sealed Connector Series Extreme Power SPEC Pak® (75 To 310 Amps)

Extreme Power SPEC Pak® (75 To 310 Amps)

Anderson Extreme Power SPEC Pak®



EXTREME POWER SPEC PAK®
(75 TO 310 AMPS)

The SPEC Pak® Extreme uses rugged and environmentally sealed (IP68) shells to protect APP Powerpole® contacts and housings. Customer configured SPEC Pak® Extreme Connectors are capable of up to 320 amps and may be used anywhere a rugged and/or waterproof high power, signal and ground interconnect solution is required.

The SPEC Pak® Extreme shell accepts 75 to 180 amp Powerpole® contacts. The wide range of Powerpole® housing colors and contact sizes, coupled with the available Powerpole® holders, offers the user a wide array of design options. Flexibility can be enhanced by replacing a PP120 housing with the PP 15/45 adapter to provide auxiliary signal options. Wire sizes ranging from 20 to 3/0 AWG (0.5 to 85.0 mm2) can be accommodated. SPEC Pak® Extreme is highly configurable with thousands of design options in a single interconnect.

Anderson Power Products

EXTREME POWER SPEC PAK® (75 TO 310 AMPS) FEATURES

  • Environmentally sealed (IP68) shells

  • Rugged, safe & versatile shells

  • 310A per contact at 600 volts

  • Power, signal & ground contacts available

  • Up to 9 power circuits

  • 4 standard insert arrangements available

  • Color-coding capabilities for ease of assembly

  • Other configurations available
