AU-06PMMP-LC7001

Amphenol

MINI PANEL LOCK 6 M M

WATERPROOF CIRCULAR CONNECTORS FOR INDUSTRIAL APPLICATIONS

Amphenol LTW Circular Connectors are waterproof (rated to IP68) and are available as receptacle, receptacle with cable, overmolded with cable and field installable.

This Amphenol LTW Circular Connector series is available in five sizes, from mini, standard, middle, large and macro. Mating styles include bayonet, screw thread and push lock.

The durability and water-resistance of these Amphenol LTW circular connectors makes them a perfect choice for industrial applications offering ≤10mΩ contact resistance, ≤100MΩ at DC500V insulation resistance, and at least 1000 mating cycles.

Amphenol LTW Circular Waterproof Connectors are available as a receptacle, receptacle connector with cable, and over-molded with cable.

Amphenol LTW Connector Features:

  • Current rating / data: 2A, 5A, 10A, 20A, 5A+2A, 10A+5A, 20A+2A, 20A+5A
  • IP66-68 waterproof rating
  • Temperature ranges from -20°C to +105°C
  • ≤10mΩ contact resistance
  • ≤100MΩ at DC500V
  • 1000 cycles durability
  • ≥ AC 1000V / 1 minute
  • Salt spray corrosion test: 48H
  • Standard cable length: 01M to 99M

** Actual product appearance may vary **

Price Information

Available Qty: 0
Quote Qty:

Press QUOTE for price and availability (or Call us).

Price available by Quote only
Tariffs may apply. Final tariff charges are calculated at time of shipment and will appear on invoice.
PRODUCT INFORMATION
Export Class: EAR / EAR99
RoHS: Yes
Weight (lbs): 0.00500
Weight (g): Unknown
